ShapeShift® Pitch Pan

ShapeShift® Pitch Pan

ShapeShift® pitch pans consist of straight and outside corner sections that snap together to create an endless number of pitch pan sizes to seal around roof projections. The radius corner pieces measure approximately 2" x 2". The straight sections measure approximately 3" long. The high-strength polymer pieces have a 2-1/2" base flange with a 1-3/4" high side. The pieces snap together with interlocking joints. The smallest pitch pan possible is 4" x 4" (4 corner pieces). The maximum size is unlimited. ShapeShift® pitch pans are approved for installation on MuleHide warranted projects when installed on vertical surfaces if filled with JTS 1 sealant instead of MP Liquid Sealant.

Colors

  • Flexibility to create any pitch pan size
  • No-weld repair for TPO projects
  • Can be used vertically with JTS 1 - Joint & Termination Sealant on Mod Bit or single-ply membrane systems (priming is required when used with single-ply membrane)
  • Can be used horizontally on Mod Bit systems when filled with JTS 1 - Joint and Termination Sealant, MP Liquid Sealant or One-Part pourable sealer

Documents

PDS - ShapeShift Pitch Pan
View English
View Spanish

Maintenance & Repair Brochure
View English
View Spanish
Sell Sheet - ShapeShift Pitch Pans
View English
View Spanish

Details

Vertical Sealant Pocket - All EPDM Systems
View English DWG
Vertical Sealant Pocket - All PVC Systems
View English DWG
Vertical Sealant Pocket - All TPO Systems
View English DWG

Options

Item ID Description Packaging Qty per Ctn Weight per Ctn Cover Rate
08MHSSPS16 MH SHAPESHIFT PITCH PAN STRAIGHTS 16/CTN CTN 16 2
08MHSSPC16 MH SHAPESHIFT PITCH PAN CORNERS 16/CTN CTN 16 2
08MHSSPC48 MH SHAPESHIFT PITCH PAN CORNERS 48/CTN CTN 48 6

FAQs

No. Pitch pan pieces are manufactured from a white high-strength polymer.

ShapeShift pitch pans require priming on certain surfaces to ensure proper adhesion of the pan itself. Refer to the ShapeShift product data sheet for more details.

When used on EPDM, TPO or PVC/KEE HP membrane systems, appropriate primer is required. Refer to the ShapeShift product data sheet for more details.

No, not at this time. Although it can be made in any size, the pans must be either a square or a rectangle.

MP Liquid Sealant is available in White, Black or Gray in 2-liter foil pouches (4 pouches/per pail).

Absolutely, and it is approved for use on MHP system warranties. When filled with JTS 1 sealant, ShapeShift pans provide an excellent way to flash those troublesome cables or conduits that penetrate parapet walls when a prefabricated pipe boot or split pipe boot will not work.

Cartons are available in straights and corners. A carton of straights contains 16 pieces. A carton of corners contains 48 or 16 pieces.

The threaded cap on the foil pouches allows any unused product to be saved for up to 30 days after opening.
